Overview

The HUX-30 series low-voltage distribution box is a terminal power distribution device for installing modular electrical appliances with an integral multiple of 9mm in width. The box and panel are made of metal materials by bending and welding. The panel is embedded with a transparent small door, which can be installed in clear and concealed ways. The box is equipped with insulating base, grounding and neutral terminals and top cap guide rail, and inlet and outlet holes are opened at the upper, lower and bottom. The UX-30 series distribution box is suitable for control circuits of 380V/220V three-phase five wire system and single-phase three-wire system. The installation width is 9mm modulus

Normal working and installation conditions

1. Installation method: Flush mounted on hollow wall, Surface mounted on non-combustible wall；

2. Ambient temperature: Limited temperature -25℃～+60℃;

3. The highest temperature during the building process: +60℃;

4. Installation method: Open the small door, unscrew the left and right screws on the door frame, remove the panel, and then install the electrical components and complete sets of wiring. After installing the wiring, cover the panel and tighten the screws on the door frame;

5. Safety protection: When electrical components are installed in the cabinet, it is necessary to ensure that the cabinet is reliably grounded.
