Overview

The SBW or DBW Series Compensation AC Power Voltage Stabilizer (hereinafter referred to as “voltage stabilizer”) is designed by our factory to stabilize AC voltage by introducing and absorbing advanced technologies from home and abroad, combined with China's national conditions. The voltage stabilizer automatically keeps the output voltage stable when the power grid fluctuation is caused by the external power supply network voltage fluctuation or load change.

Compared with other types of voltage stabilizers, this series of voltage regulators is characterized by large capacity, high efficiency, no waveform distortion, stable voltage regulation, and applicable wide load. This series of products is also able to withstand instantaneous overload, and support long-term continuous work, and optional manual and automatic switching. Meanwhile, this series is equipped with the automatic protection device for the overvoltage, undervoltage, overcurrent, phase sequence and mechanical failure, as well as has the advantages of small size, light weight, convenient use and installation, and reliable operation. It can be widely used in large electromechanical equipment, metal processing equipment, elevator and medical equipment, computer control equipment in the computer room, embroidery and textile equipment, air conditioning, radios and televisions, and household appliances and lighting equipment in the fields of industry, agriculture, transportation, post and telecommunications, military, railway, scientific research and culture.

Normal Operating Conditions

1. Ambient temperature: -5°C~+40°C

2. Altitude: Not higher than 1,000 meters.

3. Relative humidity: 15%~90% (at 20°C)

4. The installation site shall be free of gas, steam, chemical deposits, dust, dirt or other explosive and corrosive media that seriously affect the insulation of the voltage regulator.

5. The installation site shall be free from severe vibration or turbulence.
